Advantech WISE-4600 2AI/2DI/1DO/1RS-485 I/O Module (WISE-S617-A)
Deskripsi
| Category | Attribute | Value |
| Analog Input | Burn-out Detection | Yes |
| Analog Input | Channels | 2 |
| Analog Input | Input Range | ±1 V, ±5 V, ±10 V, 0~1 V, 0~5 V, 0~10 V, 0~20 mA, 4~20 mA, ±20 mA |
| Analog Input | Isolation Protection | 2,000 VDC |
| Analog Input | lnput Type | V, mV, mA |
| Analog Input | Resolution(Bits) | 16-bit |
| Analog Input | Sampling Rates(S/s) | 1Hz (per channel) |
| Analog Output | Drift | ±50 ppm/°C |
| Serial Communication | Baud Rate (bps) | 1200 bps~115.2 kbps |
| Serial Communication | Data Bits | 7, 8 |
| Serial Communication | Data Signals | RS-485: DATA+, DATA- |
| Serial Communication | Flow Control | Auto |
| Serial Communication | Parity | None, Even, Odd |
| Serial Communication | Stop Bits | 1, 2 |
| I/O Interface | Serial Ports | 1 x RS-485 |
| Digital Input | Channels | 2 (TTL) |
| Digital Input | Input Voltage | Dry Contact Logic level 0: Open Logic level 1: Close to DI COM |
| Digital Output | Channels | 1 (TTL) |
Informasi Tambahan
| Brand |
Advantech |
|---|
